Standard Pressure Gauge ST

- As a basic pressure gauge manufactured based on JIS B 7505
- Bourdon tube pressure gauge standard, you can use this widely.
- Areliable pressure gauge with abundant production results

Detail

Sealing Case Pressure Gauge WP

- "Inserting an O ring or a rubber packing in the joint part, it maintains stable sealing properties" and protects the internal structure.
- It can be used under rain, dew environment. (IP54 equivalent)
- The internal structure adopted the proven ST shape and took over the reliability.

Detail

Stainless Steel Pressure Gauge WS

- All main parts are made of stainless steel (except for some parts like a scale, which are not functionally necessary), it is robust and excellent in corrosion resistance.
- An all-round pressure gauge that can be used anywhere. (IP54 equivalent)
- Electrolytic polishing is applied, it is suitable for medical and food use.

Detail

Plastic case Pressure Gauge PC

- We adopted ABS resin for the case and made it cost-effective.
- Ideal for rust-prone places such as in the water use sections that do not require so tight sealability than where a closed type is needed.

Detail

Glycerin filled Pressure Gauge GR

-To protect the internal mechanism and ensure excellent durability and vibration resistance, glycerin is encapsulated inside the pressure gauge.
-Ideal for places of violent vibration and pulsation, which were considered impossible with a pressure gauge.

Detail

Pressure Gauge with Electric Contacts (Micro Switch Type) MS

- The adapted micro switch is a proven standard from and it imporoved the reliability.
- When set pressure is reached, it activates switch to use for alarm or control.

Detail

Pressure Gauge with Electric Contacts (Contact Switch Type) CS

- When set pressure is reached, it activates switch to use for alarm or control.

Detail

Small Size Pressure Gauge KG

- "Compact pressure gauge perfect for incorporation into a machine or equipment."
- The maximum pressure range is ultra-wide, with 0.1 to 40 Mpa (size 40, 50) and it covers from " pneumatic equipment to high pressure hydraulic equipment."
- We can respond flexibly to custom made requests such as name insertion and special additional processing.

Detail

Twin Needle Pressure Gauge DP

- Space saving by displaying two sites' pressures in one pressure gauge.
- It is perfect in comparing two pressures.

Detail

Differential Pressure Gauge DF

- Indicate pressure difference between 2 points
- Measurement of flow rate, measurement of clogging of filter, measurement of internal and external pressure difference in clean room

Detail

Gear-less Pressure Gauge (Link Type) RS

- A pressure gauge that does not use gears for the enlarging mechanism and improves durability.
- The link formula instructs the displacement of the Bourdon tube to the pointer using the link.

Detail

Gear-less Pressure Gauge (Spiral Type) SP

- A pressure gauge that does not use gears for the enlarging mechanism and improves durability
- The spiral type winds the Bourdon tube a number of times to set the pointer and directs the pressure.
- Spiral type has marvelous durability because of no sliding part, therefore ultra miniaturization can be realized.
- It is used for pulsating pressure measurement of a Plunger type pump and a portable cylinder for aircraft.

Detail

Micromanometer (Indoor use Type) MP1

- It is used for low pressure measurement which can not be taken with an ordinary pressure gauge of 60 kPa (6000 mmH2O) or less.

Detail

Micromanometer (Drip-proofed Type ) MP2

- It is used for low pressure measurement which can not be taken with an ordinary pressure gauge of 60 kPa (6000 mmH2O) or less.
- The case is drip-proofed (IP 22 equivalent).

Detail

SUS Bellows Gauge Micronanometer MP3 Type

・It is used for low pressure measurement which can not be taken with an ordinary pressure gauge of 60 kPa(6000 mmH2o) or less.

Detail

Pressure Gauge for General Gas OG

- It is used for gas pressure measurement of oxygen, acetylene, hydrogen, helium, etc.
- Gas leak test, adoption of safety blowhole and self-extinguishing resin and thorough safety measures.
- Completely dry treatment that does not emit any harmful water or oil to connected equipment such as pressure regulator.

Detail

Pressure Gauge for High Purity Gas HC

- It is used for gas pressure measurement of oxygen, acetylene, hydrogen, helium, etc.
- Gas leak test, adoption of safety blowhole and self-extinguishing resin and thorough safety measures.
- Completely dry treatment that does not emit any harmful water or oil to connected equipment such as pressure regulator.
- For high-purity gases, airtightness and cleanliness are fully considered, making it ideal for semiconductor process.

Detail

Pressure Gauge for High Pressure Gas HP

- It is used for gas pressure measurement of oxygen, acetylene, hydrogen, helium, etc.
- Gas leak test, adoption of safety blowhole and self-extinguishing resin and thorough safety measures.
- Completely dry treatment that does not emit any harmful water or oil to connected equipment such as pressure regulator.
- For high-pressure hydrogen gas which has a material considering hydrogen embrittlement, a bulkhead is provided to allow the gas to escape backward in the rupture of the Bourdon tube in the unlikely event.

Detail

Diaphragm Pressure Gauge (Direct Connection Type) SA

- Provided a diaphragm so that fluid does not enter directly into the pressure gauge.
- For the measurement of corrosive fluid, high viscosity fluid in chemical plants, food factories, etc.
- No oil treatment is done for all models.

Detail

Diaphragm Pressure Gauge (Remote Sensing B Type) SB

- Provided a diaphragm so that fluid does not enter directly into the pressure gauge.
- For the measurement of corrosive fluid, high viscosity fluid in chemical plants, food factories, etc.
- Possible to separate the pressure receiving part and the indicating part as a separate type.
- No oil treatment is done for all models.

Detail

Diaphragm Pressure Gauge (Remote Sensing D Type) SD

- Provided a diaphragm so that fluid does not enter directly into the pressure gauge.
- For the measurement of corrosive fluid, high viscosity fluid in chemical plants, food factories, etc.
- Possible to separate the pressure receiving part and the indicating part as a separate type.
- No oil treatment is done for all models.

Detail

Pressure Gauge 0.6 Class MA

- High precision pressure gauge for test or inspection

Detail
